Scan mode 0.75 - 300mm Ultrasonic Thickness Gauge TG3100 for epoxies, glass

Scan mode 0.75 - 300mm Ultrasonic Thickness Gauge TG3100 for epoxies, glass
Scan mode 0.75 - 300mm Ultrasonic Thickness Gauge TG3100 for epoxies, glass

Large Image :  Scan mode 0.75 - 300mm Ultrasonic Thickness Gauge TG3100 for epoxies, glass

Product Details:

Place of Origin: Beijing
Brand Name: Huatec
Certification: CE, GOST
Model Number: TG-3100

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Packaging Details: Carton Package
Delivery Time: 3-5 working days
Payment Terms: Paypal / Western Union / TT
Supply Ability: 1000
Detailed Product Description

Detailed Product Description



Features
1.Capable of performing measurements on a wide range of material, including metals, plastic, ceramics, composites, epoxies, glass and other ultrasonic wave well-conductive materials.
2.Transducer models are available for special application, including for coarse grain material and high temperature applications.
3.Two-Point Calibration function.
4.Two work modes: Single point mode and Scan mode.
5.Coupling status indicator showing the coupling status.
6.Optional software to process the memory data on the PC.
7.Optional thermal mini-printer to print the measured data via RS232 port.

Specifications
1.Display:4.5 digits LCD with EL backlight.
2.Measuring Range:0.75~300mm (in Steel).
3.Sound Velocity Range: 1000~9999 m/s.
4.Resolution: 0.1/0.01mm
5.Accuracy: ±(0.5%Thickness+0.04)mm, depends on materials and conditions
6.Units: Metric/Imperial unit selectable.
7.Four measurements readings per second for single point measurement, and ten per second for Scan Mode.
8.Memory for up to 20 files (up to 99 values for each file) of stored values.
9.Power Source:Two AA size, 1.5 Volt alkaline batteries. 100 hours typical operating time (EL backlight off).
10.Communication:RS232 serial port.
11.Outline dimensions:150×74×32 mm.
12.Weight:245g

Configuration

No
Item
Quantity
Note


Standard Configuration
1
Main body
1

2
Transducer
1
Model: N05/90°
3
Couplant
1

4
Instrument Case
1

5
Operating Manual
1

6
Alkaline battery
2
AA size
7



8





Optional
Configuration
9
Transducer: N02

Appendix A
10
Transducer: N07

11
Transducer: HT5

12
Mini thermal printer
1

13
Print cable
1
14
DataPro Software
1
15
Communication Cable
1

Probe optional (Appendix A):



Model
Freq. MHz
Diam. Mm
Measuring range
Lower limit
Description
N02
2
22
3.0mm-300.0mm (in steel)
20
For thick, highly attenuating, or highly scattering materials
N05
5
10
1.2mm-230.0mm (in steel)
¢20mm×3.0mm
Normal measurement
N05/90°
5
10
1.2mm-230.0mm (in steel)
¢20mm×3.0mm
Normal measurement
N07
7
6
0.75mm-80.0mm (in steel)
¢15mm×2.0mm
For thin pipe or small curvature
pipe wall thickness measurement
HT5
5
14
3mm-200mm (in steel)
30
For high temperature measurement (up to 300℃)



--------------------------------------------------------------------------------------------------------------
